ANDROID/CONCEPT

[Android] 06강. 액티비티 화면 전환 (Activity Change)

너래쟁이 2018. 3. 26. 22:59

activity_main.xml

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context="com.example.kbw.a6.MainActivity">
    ​
    <EditText
        android:id="@+id/nameText"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentTop="true"
        android:layout_centerHorizontal="true"
        android:layout_marginTop="59dp"
        android:ems="10"
        android:hint="Name"
        android:inputType="textPersonName"
        android:text="Name" />
    ​
    <Button
        android:id="@+id/nameButton"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_below="@+id/nameText"
        android:layout_centerHorizontal="true"
        android:layout_marginTop="23dp"
        android:text="Send" />
</RelativeLayout>
cs


activity_sub.xml

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:orientation="vertical"
    android:layout_width="match_parent"
    android:layout_height="match_parent">
    ​
    <TextView
        android:id="@+id/nameText"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentLeft="true"
        android:layout_alignParentStart="true"
        android:layout_alignParentTop="true"
        android:text="TextView"
        android:textAppearance="@style/TextAppearance.AppCompat.Display2" />
</RelativeLayout>
cs


AndroidMainifest.xml

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.example.kbw.a6">

    <application
        android:allowBackup="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:supportsRtl="true"
        android:theme="@style/AppTheme">
        <activity android:name=".MainActivity">
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
        <activity android:name=".SubActivity">
        </activity>
    </application>
</manifest>
cs


MainActivity.java
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
package com.example.kbw.a6;

import android.content.Intent;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;
import android.widget.EditText;

public class MainActivity extends AppCompatActivity
{
    @Override
    protected void onCreate(Bundle savedInstanceState)
    {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        final EditText nameText = findViewById(R.id.nameText); // 사용자가 이름을 입력하면 저장하는 객체
        Button nameButton = findViewById(R.id.nameButton); // 다음페이지에 넘어가면서 이름값을 전달해주는 역할
        nameButton.setOnClickListener(new View.OnClickListener()
        {
            @Override
            public void onClick(View v)
            {
                String name = nameText.getText().toString();
                Intent intent = new Intent(getApplicationContext(), SubActivity.class); // 새로운 창을 만들기위한 객체
                intent.putExtra("nameText", name); // intent를 통해 SubActivity를 시작하고, 데이터를 넘긴다
                startActivity(intent);
            }
        });
    }
}
cs



SubActivity.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
package com.example.kbw.a6;

import android.content.Intent;
import android.os.Bundle;
import android.support.annotation.Nullable;
import android.support.v7.app.AppCompatActivity;
import android.widget.TextView;

/**
 * Created by kbw_ on 2018-03-26.
 */

public class SubActivity extends AppCompatActivity // SubActivity도 하나의 창이기때문에 상속받는다
{
    @Override
    protected void onCreate(@Nullable Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_sub);
        TextView nameText = (TextView)findViewById(R.id.nameText);
        Intent intent = getIntent();
        nameText.setText(intent.getStringExtra("nameText").toString());
    }
}
cs
